Plastic PP PE Carbon Fiber Air Cooling Granulation Production Line 600kg/h

Large Image : Plastic PP PE Carbon Fiber Air Cooling Granulation Production Line 600kg/h

Product Details:

Place of Origin:	China
Brand Name:	PLASTAR
Certification:	CE, ISO9001
Model Number:	PL500

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Dollar 25000-85000$
Packaging Details:	wood box+wood pallet+stretch film package
Delivery Time:	30-50 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100sets/year

Contact Now

Detailed Product Description

Raw Material:	PLA, PBAT, PP, PE, Carbon Fiber	Processing Capacity:	100-1500kg/h
Screw Design:	Single Screw Extruder	Cutting Type:	Strand Cutting Type
Machine Type:	Mother Baby Extruder Or Two Stages Extruder	Feeding Type:	Force Feeding Or Compactor
Degassing Device:	Vacuum Degassing	Screen Changer:	Without Mesh Type Filter
Main Motor Brand:	Siemens Beide	Name:	Plastic Recycling Pelletizing Line
High Light:	93mm screw granulation production line , PLASTAR pp granules making machine , PLASTAR granulation production line

Plastic PP PE Carbon Fiber Air Cooling Granulation Production Line

The pelletizing line is used for dispersing, filling and compounding plastic resin.
The production line uses parallel co-rotating twin-screw extruders with a length-to-diameter ratio of 40-44:1.
The production line has a large output.
The production line is equipped with a vibrating screen, which can filter large particles.

We have different model machine for you choose:

Mode	Screw Diameter D(mm)	Screw Length(mm)	L/D	Screw Rater N(r/min)	Motor Power P(kw)	Torque T(N.m)	Torque Level T/N3	Capacity Q(kg/h)
SJH-20	22	150	32-44	600	5.5	43	7.5	0.5-10
SJH-30A	31		32-48	500	11	105	5.9	5-30
SJH-30B	31		32-48	600	15	119	6.7	5-40
SJH-35A	35.6		32-48	600	15	119	4.4	20-60
SJH-40A	41	160	32-64	400	22	263	6.4	65-110
SJH-40B	41	160	32-52	600	30	239	5.8	90-150
SHJ-50A	50.5		32-52	500	45	430	5.4	135-225
SJH-52B	51.5	210	32-64	600	55	438	5.5	225-250
SJH-52C	51.5	210	32-64	600	75	597	7.5	200-300
SJH-65A	62.4	240	32-52	400	75	895	6.3	180-250
SJH-65A	62.4	240	32-52	500	75	716	5.1	180-250
SJH-65B	62.4	240	32-64	600	90	716	5.1	200-300
SJH-75A	71	290	32-56	400	90	1074	5.0	225-350
SJH-75A	71	290	32-56	500	110	1050	4.8	250-450
SJH-75B	71	290	32-64	600	132	1050	4.8	350-550
SJH-75D	71	290	32-64	60O	220-250	1990	9.2	500-1000
SJH-95A	93	360	32-64	500	250	2387	5.0	600-1000
SJH-95B	93	360	32-64	600	315	2506	5.3	800-1200
SJH-135A	133		32-64	500	750	7162	5.38	1500-225

Plastic PP PE Carbon Fiber Air Cooling Granulation Production Line 600kg/h 0
