400kg/H Plastic Pelletizing Recycling Machine PP Spunbond Non Woven Fabric Agglomerator

Large Image : 400kg/H Plastic Pelletizing Recycling Machine PP Spunbond Non Woven Fabric Agglomerator

Product Details:

Place of Origin:	China
Brand Name:	PLASTAR
Certification:	CE, ISO9001
Model Number:	PL500

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Dollar 25000-85000$
Packaging Details:	wood box+wood pallet+stretch film package
Delivery Time:	30-50 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100sets/year

Contact Now

Detailed Product Description

Raw Material:	PP PE ABS PET HDPE, LDPE Etc	Screw Design:	Single Screw Extruder
Screen Changer:	No Stop Automatic Hydraulic Screen Changer	Screw Material:	38CrMoAL
Processing Capacity:	100-1500kg/h	Machine Type:	Single Stage Or Double Stage
Degassing Device:	Vacuum Degassing	Main Motor Brand:	Siemens Beide
Name:	Plastic Recycling Pelletizing Machine
Highlight:	Non Woven Plastic Pelletizing Recycling Machine , PP Spunbond recycling granulator machine , PP Spunbond Plastic Pelletizing Recycling Machine

PP Spunbond Non Woven Fabric Agglomerator Pelletizing Recycling Machine

PP Spunbond Non Woven Fabric Agglomerator

PSD series compacting pelletizing system, it is a three in one recycling machine designed for low density plastic articles. It could provide the excellent re-pelletizing and recycling solution for film, raffia, filament, woven bag and nonwoven fabric and other consumed / post soft or rigid plastic. Our pellet making machine has a wide application in PE, PP, CPP, BOPP, PS, PPS, EPS, ABS, PA, PLA, PET waste plastic materials recycling field.

What kind of raw materials are processable with our machines?

400kg/H Plastic Pelletizing Recycling Machine PP Spunbond Non Woven Fabric Agglomerator 0
What's the machines working principle?

400kg/H Plastic Pelletizing Recycling Machine PP Spunbond Non Woven Fabric Agglomerator 1

PLASTAR provides four different pelletiizng solutions for you aiming at different MFI polymer will get different shape output pellets.
Detail Specification

400kg/H Plastic Pelletizing Recycling Machine PP Spunbond Non Woven Fabric Agglomerator 2

●The plastic material feed through belt conveyor get into the compactor.
●Metal detector can be installed on conveyor, to protect the compactor and extruder machine.

●The rotatory blades of compactor will cut up incoming scraps.
● Frictional heating which caused by high speed rotatory blades and stationary blades will heat and let scraps shrinking just below their agglomerating point.
● Optimal designed guide structure compacts the material and directs it into extruder screw.

●A specialized single screw extruder applied to gently melt the pre-compacted material.
●The plastic scraps will be well melted, plasticized in the extruder.
●With double-zone vacuum degassing system, volatiles such as low molecular and moisture will be removed efficiency, especially suitable to heavy printed film and material with some water content.

●A screen changer can be installed before die head to remove some metal, wood, dust, paper such impurities to get high quality output plastic melt.

●Die-face water ring pelletizing system set as the standard granulating method to get uniform size plastic pellets.
●The pellets would be cooled by water and dried by centrifugal dryer and finally conveyed into storage silo.

●Top brand components. ●PLC controller and HMI screen.
●One button start & stop. ●Multi-language operating system.
Main Features
●Ability:
PLASTAR pelletizing system with superior quality which have high productivity for PP/PE/PS/ABS/BOPP/CPP plastic could get high property output pellets.
●Stability:
The pelletizing system is available for 24 hours working non-stop operation.
●Efficiency:
The pelletizing system have very low consumption values for electricity, water and labor.

●Control:
Intelligent automatic control of pelletizing system reduces the labor operation, makes the whole system easier and more reliable to control.
●Service:
Consistently quick and careful service in pre-sales and after-sales process. Overseas installation, commissioning and training are available.

400kg/H Plastic Pelletizing Recycling Machine PP Spunbond Non Woven Fabric Agglomerator 3

Technology Parameter
Type		PSD80	PSD100	PSD120	PSD140	PSD160	PSD180
Capacity (kg/h)		150-250	300-420	400-600	600-750	800-950	1000-1200
Energy consumption (kWh/kg)		0.2-0.33	0.2-0.33	0.2-0.33	0.2-0.33	0.2-0.33	0.2-0.33
A / Length (mm)		10,300	10,300	11,400	11,400	14,800	14,800
B / Width (mm)		6,200	6,200	6,450	6,450	6,850	6,850
C / Height (mm)		3,500	3,750	3,980	4,250	4,460	4,850
Compactor	Volume(L)	300	500	800	1000	1200	1400
Compactor	Motor power(KW)	37-45	55-75	75-90	90-132	132-160	160-185
Extruder	Screw Diameter (mm)	φ80	φ100	φ120	φ140	φ160	φ180
	L/D	30-40	30-40	30-40	30-40	30-40	30-40
	Motor power (kW)	55-75	90-110	132-160	160-200	250-315	315-355
Filter (options)	Two position plate type	●	●	●	●	●	●
	Two position piston type	○	○	○	○	○	○
	Back flush piston type	○	○	○	○	○	○
	Automatic self-cleaning type	○	○	○	○	○	○
2nd Extruder (optional)	Screw Diameter (mm)	φ100	φ120	φ140	φ160	φ180	φ200
	L/D	10-18	10-18	10-18	10-18	10-18	10-18
	Motor power (kW)	37-45	45-55	55-75	75-90	90-110	110-160
Downstream (options)	Water ring pelletizer	●	●	●	●	●	●
	Strand pelletizer	○	○	○	○	○	○
	Auto strand pelletizer	○	○	○	○	○	○
	Underwater pelletizer	○	○	○	○	○	○

● Standard  ○ Alternative

PLASTAR MACHINE HOW TO ENSURE THE QUALITY!

● In order to ensure the accuracy of each part, we are equipped with a variety of professional processing equipment and we have accumulated professional processing methods over the past years.
● Each component before assembly needs strictly control by inspecting personnel.
● Each assembly is in charged by a master who has working experience for more than 20 years
●After all the equipment are completed, we will connect all the machines and run the full production line to ensure the stable
running in customers' factory

THE AFTER-SALE SERVICE OF PLASTAR MACHINERY!

● After finishing the production, we will debug the production line, take photos, videos and send them to customers via mail or instant tools
● After the commissioning, we will package the equipment by standard export package for shipment.
● According to the customer's request, we can arrange our engineers to customers' factory to do the installation and training.
● Engineers, sales managers and after-sales service manager will form a after-sales team, online and off line, to follow the customers' project.

Would like to know more about PLASTAR Machine equipments, feel free to send us an inquiry!
